Safe Speed Monitoring Modules

Safe Speed Monitoring Modules

Product Details:

X

Product Description

Overview :

  • Feedback input monitors external machine control elements
  • 24V ac/dc operation
  • Two redundant, forced guided output contacts rated at 4A, plus one auxiliary N.C. output contact
  • Stop Category 0, per ISO 13850 (EN 418), IEC 60204-1, and ANSI NFPA 79; Category 3, SIL Claimed Level (SIL CL) 3 to EN 62061, Category 3 / Performance Level (PL) e to DIN EN ISO 13849-1
  • DIN-rail mountable 45 mm wide housing with removable terminal blocks
  • Energizes output relays (closes N.O. contacts), when speed drops below set value, for "standstill" (under-speed) monitoring
  • De-energizes output relays (opens N.O. contacts), when speed rises above set value, for over-speed monitoring
